Proscenium Height: 40′
Proscenium Width: 45′
Grid Height: 80′ to walking surface
Max trim of system pipes: 77’
Fire Curtain to Back Wall: 54’
Stage Left Wing: 57’w x 42’d
Stage Right Wing: 29’-6”w x 54’d
Apron: 4’-2” (from fire curtain)
Stage Height (from seating level): 3′-4″
Orchestra Pit Width: 55′
Orchestra Pit Depth @ Center Line: 9’-8”
Orchestra Pit Performance Position: 9’ below stage level
Orchestra Pit highest Level: stage level
Orchestra Pit Lowest Level: 24’ below stage level

*The orchestra pit is on an electrically-powered GALA Lift with 23,000 lbs capacity Distance from Pit Wall to Row 1 4′
